B1N1C1 – NOARK 1P 1A 240VAC/60VDC DIN RAIL 10kA BREAKER
The B1N1C1 NOARK 1P 1A 240VAC/60VDC DIN Rail Breaker is a reliable choice for protecting your electrical systems. With a high breaking capacity of 10kA, it ensures optimal safety and performance. This compact circuit breaker is designed for easy installation on DIN rails, making it an ideal solution for your needs.
The 'C' in B1N1C1 refers to the IEC trip curve — a Type C characteristic, which trips at 5–10× the rated current and is suited for general loads with moderate inrush (motors, transformers, lighting). The '1' is the ampere rating (1 A). NOARK's B1N series is also available in Type B (3–5×) for more sensitive loads. Contact us if you need a different curve or ampere rating.
Yes — the B1N1C1 is rated for both 240VAC and 60VDC, making it suitable for DC control circuits, battery systems, and renewable-energy applications up to 60 V DC. Always verify polarity markings and follow the manufacturer's wiring instructions for DC applications to ensure the rated 10 kA interrupting capacity is maintained.
Yes — Northern Breaker Group specialises in sourcing both current-production and hard-to-find breakers across Canada, with counter locations in Calgary, Edmonton, and Vancouver. If the B1N1C1 is out of stock locally, we can quote on availability and lead time. Reach out with your required quantity and we'll get back to you promptly.
